Special Shaped Rectangular Tank

A customer needed a special shaped rectangular tank for a specific requirement.

resultant displacement
bottom tank static

There was a bit of doubt about how much the long side would bulge under normal hydrostatic conditions, so we ran an FEA analysis and found theoretically it would bulge out 17mm. We added an internal baffle which resulted in the long side having a minimal and acceptable distortion

special rectangular tank
bulge out 17mm special tank

Custom Fabrication

All built from scratch with pride and care in our Minto workshop

Contact us for a bespoke system to suit your specific needs
